RIP/RIF Oil-Oil Transformer Bushing
Rated Voltage: 40.5kV - 550kV
Rated Current: 630A - 8000A
Dry-type Condenser Oil-SF6 Transformer Bushing
RIP Oil/Oil Transformer Bushing
RIF Oil/Oil Transformer Bushing
Dry-type RIP Oil Oil bushing,
RIF/RIS Oil Oil Transformer Bushing
These bushings are primarily used to connect oil-immersed transformers or rectifier transformers to cable boxes or transition tanks via an oil medium.
Proven Insulation Technology: Choose between reliable RIF or RIP solid insulation systems.
Conductor Flexibility: Supports both draw-lead and solid-stem conductor types for design adaptability.
Eliminates Leakage Risk: The monolithic solid core structure prevents any internal leakage between oil chambers, a common failure point in conventional designs.
Custom Design: Configurable for specialized applications.
For environments outside this range, the technical specifications shall be subject to agreement between the supplier and the purchaser.
Installation Angle: Can be installed at any angle.
1. Electrical Parameters:
Rated voltage, rated current, rated frequency, external insulation creepage distance, internal insulation clearance, oil-end length, draw-lead length (critical), CT mounting position length (critical).
2. Environmental Parameters: Ambient temperature.
3. Installation Details:
Please indicate if a measurement terminal is required. If yes, please provide the required installation dimensions for the terminal.
Note: The dimensions of the bushing flange and terminals can be custom-designed according to the transformer manufacturer's requirements. We also supply direct replacement bushings for existing installations.
